The M22 Basic Information preview


The Design Market

The M22 has been designed by the engineers at MoTIS VJD to be a true air taxi jet server. Jetting people from their small home airports to major airports for transport to their final destination! The M22 is not a jet aircraft built for maximum speed but maximum efficiency in this  new aspect of the aviation industry!

Copyright (C) 2002 by MoTIS Virtual Jet Design. All rights reserved


The Wind Tunnel Tests

The M22 Wing Design will be the first item on the list for discussion!

Copyright (C) 2002 by MoTIS Virtual Jet Design. All rights reserved


 The Airframe Chemistry

The M22 is made of a Aluminum (Al 26.9mw) + Carbon fibers (C 12.0mw) {Al(x)C(x)} composite mix. This virtual mixture is called AluBon. This composite mixture makes the M22 one of the lightest weight jets in the world!

Al + C = Al_C_= Alubon

=

Note: This is not a real chemical. It is Created as a fictitious chemical to give a realistic design model to the M22 Air Taxi

Copyright (C) 2002 by MoTIS Virtual Jet Design. All rights reserved


The Aircrafts Systems

The Breaking System:

The M22 has a internally gear driven breaking pump system. This system was designed by team MoTIS this way because the engine provides more thrust then the M22 actually weights. Well this is a great feature when in the air but on the ground the M22 has a tendency to roll because the engine power generated at idle is enough to push the super light Alubon composite fiber airframe. Without this type of breaking system the M22 would not be able to perform its new found aviation tasks!

Breaking System EX.

MT-HDR 500

The MT- Hydraulic Sweep Disk Relay System

Copyright (C) 2002 by MoTIS Virtual Jet Design. All rights reserved


The Aircrafts Systems

The Flight Control Linkage System:

The M22 has an internal Titanium braded linkage system, linked to an on board monitoring system that records control system pressures and auto coordinates the amount of control input the pilot can continue to add to the maneuver being executed!



o

Copyright (C) 2002 by MoTIS Virtual Jet Design. All rights reserved


 The Engine

 MoTIS engineers would like to take this time to introduce the power behind the plane, the MJ-4800 High Compression Noise Reduction Jet! This jet is designed and produced by MoTIS VJD and delivers a blasting 4850 lbs of thrust@ S.L to the M22 composite airframe!

Note: This jet engine will be covered in Virtual Test Pilot Magazine due out in October.

Copyright (C) 2002, 2004 by MoTIS Virtual Jet Design. All rights reserved

MORE INFO TO COME SOON
